D104A056-149 PCB端接面板插座连接器Fischer
发布时间：2024-04-11 09:20:25 浏览：1040
PCB端接面板插座连接器Fischer是一种用于PCB端接的连接器，具有3至27个接触点，适用于低压信号和电源传输。插座的典型端接方式为PCB焊接。该连接器的锁定系统取决于插头的设计，确保牢固的连接。它具有IP50防护等级，能够在一般工业环境中有效防尘。
（EN：PCB End Panel Socket Connector Fischer is a connector for PCB end, with 3 to 27 contact points, suitable for low voltage signal and power transmission. The typical termination method of the socket is PCB welding. The locking system of the connector depends on the design of the plug, ensuring a strong connection. It has IP50 protection rating and can effectively prevent dust in general industrial environment.）
连接器类型为插座，外壳材料为黄铜，外壳颜色为黑色哑光。绝缘材料采用PEEK，能够有效隔离电路，确保连接的稳定性和可靠性。该连接器采用面板前置安装方式，并具有正常极性。
（EN：Connector type is socket, housing material is brass, housing color is black matte. The insulation material adopts PEEK, which can effectively isolate the circuit and ensure the stability and reliability of the connection. The connector is mounted in front of the panel and has normal polarity.）
这款Fischer PCB端接面板插座连接器适用于各种PCB连接需求，广泛应用于工业控制、通信设备、医疗设备等领域。
（EN：The Fischer PCB end panel socket connector is suitable for various PCB connection needs and is widely used in industrial control, communication equipment, medical equipment and other fields.）
产品型号：
| 连接器Connector | 接触Contacts | 典型端接Termination type | 锁定系统Locking system | 信号/电源Signal / Power | 密封等级Sealing level |
| D104A056-149 | 11 | PCB | PTUg | Low Voltage | IP50 |
| 108991 | dependent |
| D104A066-139 | 8 | PCB | Plug | Low Voltage | IP50 |
| 108865 | dependent |
| D102A053-139 | 4 | PCB | Plug | Low Voltage | IP50 |
| 100419 | dependent |
| D1031A019-139 | 19 | PCB | Plug | Low Voltage | IP50 |
| 102326 | dependent |
| D102A059-139 | 9 | PCB | Plug | Low Voltage | IP50 |
| 122421 | dependent |
| D104A056-139 | 11 | PCB | Plug | Low Voltage | IP50 |
| 108311 | dependent |
| D104Z092-139 | 19 | PCB | Plug | Low Voltage | IP50 |
| 126226 | dependent |
| D105A093-89 | 24 | PCB | Plug | Low Voltage | IP50 |
| 126728 | dependent |
| D1031A019-149 | 19 | PCB | Plug | Low Voltage | IP50 |
| 129016 | dependent |
| D105A038-139 | 18 | PCB | Plug | Low Voltage | IP50 |
| 129526 | dependent |
| D104A086-139 | 16 | PCB | Plug | Low Voltage | IP50 |
| 108052 | dependent |
| D105A110-139 | 16 | PCB | Plug | Low Voltage | IP50 |
| 104815 | dependent |
| D104A092-139 | 19 | PCB | Plug | Low Voltage | IP50 |
| 124506 | dependent |
| D102A059-149 | 9 | PCB | Plug | Low Voltage | IP50 |
| 129014 | dependent |
| D103A058-139 | 8 | PCB | Plug | Low Voltage | IP50 |
| 114850 | dependent |
| D102A052-139 | 3 | PCB | Plug | Low Voltage | IP50 |
| 106292 | dependent |
| D103A056-139 | 6 | PCB | Plug | Low Voltage | IP50 |
| 125893 | dependent |
| D103A054-139 | 5 | PCB | Plug | Low Voltage | IP50 |
| 135568 | dependent |
| D105A102-139 | 27 | PCB | Plug | Low Voltage | IP50 |
| 124505 | dependen |
